Tawg pov thawj Dej Chiller Industrial cua Txias 5HP

Tawg pov thawj Dej Chiller Industrial cua Txias 5HP

Specifications

• mob:

• NEW100%

• hom:

• Cua Txias

• Qhov chaw ntawm keeb kwm:

• Guangdong, Tuam Tshoj (Mainland)

• Hom Npe:

• ANYDA

• Model Number:

• Ayd-05A-EP

• Cua txias muaj rab peev xwm (kw):

• 14kw

• voltage:

• 3N-380V / 415V-50Hz

• Dimension (L * W * H):

• 1100 * 735 * 1300

• Nyhav:

• 250kg

• Certification:

• CE, ISO

• warranty:

• 1year

• Tom qab-muag Service Muab:

• Engineers muaj rau qhov kev pab machinery txawv teb chaws

• Compressor Hom:

• Copeland \ Danfoss \ Sanyo

• Compressor hom:

• scroll hermetic

• refrigerant:

• R22 / R404a / R407c

• Compressor hwj chim:

• 3.75kw

• sau:

• 4.3kg

• Cua Volume:

• 5300m3 / h

• Twj tso kua mis hwj chim:

• 0.75kw

• Yeeb Nkab Loj:

• 1 "

• Dej Flow:

• 2.4m3 / h

• Tank Volume:

• 65L

•


hauj lwm yam khoom

1. Txais tshiab mas hom tawg-pov thawj compressor, tawg-pov thawj uas tsis muaj suab nrov txaus twj tso kua mis, tshwj xeeb tawg-pov thawj hluav taws xob tswj lub thawv, raws li tshwj xeeb cheeb tsam yuav tsum tau, tawg ntau tshaj Exib Ⅱ BT4.

2. Lub tsev installation yog yooj yim, yooj yim mus ntxuav, mobile thiab saj zawg zog, tag nrho cov-hlau ntsej muag xim lub thawv, anti-xeb thiab anti-kev co kov, tsis muaj suab nrov, high efficiency tshav kub exchanger cov ntaub ntawv, siab zog efficiency tus nqi.

3. neeg siv-phooj ywg interface, high-tech, txawj ntse tswj, yooj, arbitrary, kev ruaj ntseg thiab kev thaj yeeb ntawm lub hlwb, zoo heev txias kev kawm kom tau raws li qhov tshwj xeeb tej yam kev mob.

4. Tshwj Xeeb rau tshuaj lom neeg thiab lwm yam inflammable thiab heev qhov chaw, muab nyab xeeb thiab zoo ua hauj lwm txhawb thiab tsim.

5. hnub ntse kub tswj system, tus tsim ntawm chav tsev li 24 teev uas tsis yog-nres lub lag luam.

Packing & Tus me nyuam lub sij hawm

1. Pob: Plywooden Case

2. Dellivery Lub sij hawm: 20-30 ua hauj lwm Hnub

FAQ

1.      Dej chiller muaj peev xwm muab xam

Cua txias Peev Xwm (kw) = Flow Rate (m3 / h) * Temp Hloov (T1-t2) /0.86

Thaum tshav kub kub Load = C (tej thaum tshav kub kub) * M (zis zoo ib teev) * Temp Hloov (T1-T2)

2.     Hom chiller system?

Cua Txias Chiller thiab Dej Txias Chiller.Water txias chiller xav tau ib tug cais cua txias ntauwd thiab muaj ib tug ntau dua efficiency, tab sis tsawg yooj yim dua huab cua txias.

3.     Chiller muaj peev xwm tsev?

1 kcal / h = 1.163W, 1 W = 0,8598 kcal / h;
1 Btu / h = 0.2931W, 1 W = 3,412 Btu / h;
1 USRT = 3,517 kW, 1 kW = 0,28434 USRT;
1 kcal / h = 3,968 Btu / h, 1 Btu / h = 0,252 kcal / h;
1 USRT = 3024 kcal / h, 10000 kcal / h = 3,3069 USRT;
